| MODEL |
ARES 1K |
ARES 3K |
| INPUT |
Voltage |
110Vac--300Vac ** |
| Frequency |
45Hz ~ 65Hz (Auto Sensing) |
| Phase |
Single + G |
| Power Factor |
≧ 0.99 at linear load |
| Output |
Voltage |
200/208/220/230/240 |
| Capacity |
1000VA/900W |
3000VA/2700W |
| Frequency |
3Hz or 1Hz(selectable) |
| (Synchronized Range) |
| Frequency(Battery Mode) |
50Hz/60Hz ± 0.1% unless synchronized to line |
| Current Crest Ratio |
3:1 |
| Harmonic Distortion |
< 3 % (at full linear load) |
| Output Waveform |
Pure sine wave |
| Transfer time(AC to DC) |
0 ms |
| Efficiency |
90% (Line mode) |
| DC start |
Yes |
| Battery |
Number of batteries |
4 |
12 |
| Type |
Sealed Lead Acid Maintenance Free |
| Capicity |
12V/9AH |
| Rated Battery Voltage |
24Vdc |
72Vdc |
| Recharge time (to 90%) |
3~6 hours |
| Display |
LED |
Standard |
Load Level/Battery Level/ Battery Mode/ Normal Mode/Bypass Mode/ Self-Test/ Weak/Bad Battery/Site Wiring Fault/ Fault/ Overload |
| Self Diagnostics |
Front Panel or Software Control |
| Button |
On/Alarm Silence Button)/ OFF Button/ Test/Level Button |
| Alarm |
Audible and Visual |
Line Failure, Battery Low, Overload, System Fault Conditions |
| Protection |
Over Temperature |
Bypass or Shutdown Immediately |
| Physical |
Dimensions (HxWxD in mm) |
440x88x450 |
440x176x600 |
| Outlet |
(1) Schuko + (3) IEC 320-C13 |
(2) Schuko + (6) IEC 320-C13 |
| Environmental |
Operation Temperature |
0-40℃ |
| Noise Level |
＜50dBA |
| Altitude |
1000 m without de-rating |
| Humidity |
0 to 90% (Without condensation) |
| Interface |
Interface Type |
RS232 |
| Compatible platforms |
Microsoft Windows series, Linux, Mac, etc. |
|
|
|
|
|
|
|
| *Specifications subject to change without notice. |
|
|
|
|
| ** Base on load percentage |
|
|
|
|
|
