| Model |
2Kva /1400 Watts |
| Input |
Voltage (Vac) |
80~140 |
| Frequenc y (Hz) |
50 / 60± 5%(Auto Sensing) |
| Phase |
Single |
| Input Power Factor |
> 0.98(Full Load) |
| Output |
Voltage (Vac) |
100/110/115/120 |
| Capacity(VA/W ) |
2000/1400 |
| Wave Form |
Sine Wave, THD<3%(no load to full load) |
| Voltage Regulation |
± 2% |
| Frequenc y Stabilit y |
± 0.5Hz (Free Running) |
| Transient Response(ms) |
+/-4% Under full load step and corrected within 60ms |
| Synchronization |
1 Hz/Sec. Slew Rate: Inverter Free Running If Input Frequency Over ±5% Range |
| Crest Factor |
3 : 1 |
Transfer Time
(Line Fault) |
0 ms |
| Efficiency (AC to AC) |
> 83% |
| Run Tim e(Full Load) |
25%=49m, 50%=20m, 75%=11m, 100%=8m |
| DC Start |
Yes |
| BATTERY |
Type
|
Sealed Maintenance Free Lead Acid |
| Quantity (pcs) |
6 x12V |
| Voltage (Vdc) |
72 |
| Recharge Time |
8 Hours To 90% |
| DISPLAY |
LED |
Utility, Battery Low, Inverter, Bypass, Self-Test, Load
Level, Battery Level, Overload, Fault Conditions |
| PROTECTION |
Overload
|
100%~120% delay 60 seconds before switching to bypass; 120%~150% delay 10 seconds before switching to bypass; >150% immediately switch to bypass |
| Short Circuit |
a) Inv. Mode: UPS shutdown and Cut the Output.
b) Bypass Mode: AC Input fuse Breaks down. |
| Overheat |
a) Utility Normal: Switch to Bypass.
b) Utility Abnormal: Buzzer sounds continuously,
Fault LED lights up then cut the output. |
High Voltage
Trip-Off |
Switch to Back up Mode |
Battery Low
|
Alarm continuousl y till battery cutoff |
| Noise Suppression |
Comply with EN50091-2.
|
| Spike Suppression |
Comply with EN61000-4-5. |
| ALARM |
Audible and Visual |
Line Failure, Battery Low, Transfer to Bypass, Overload, System Fault Conditions |
| PHYSICAL |
Dimensions (WxHxD, mm)
|
440x270x446 /17.32 x 6.1x 11.0 |
| Net W eight (Kgs) |
25Kg/ 55.1 LBS |
| Oulets(IEC/Local) |
for detailed information, please refer to Chapter 3.3. |
| ENVIRONMENT |
Tem perature |
-15c~+50c For extended temp range use external batteries only! |
| Hum idity |
5~90% RH Maximum, Non -Condensing |
Noise
|
<45 dB (at 1 m eter) |
| COMPUTER INTERFACE |
Interface Type |
Standard RS232 Interface |
| Protocol |
MegaTec RUPS II |
| SNMP |
Yes, Standard SNMP Card Included |
| Operating Systems Compatibility |
Novell Netware, Windows, OS/2, NetLite, MS-DOS, HP-UX, AIX, SUN OS, UNIX, XENIX. Linux,etc |
SNMP TCPIP.
