| Capacity |
10KVA |
20KVA |
30KVA |
40KVA |
60KVA |
| Environment |
| Operation Temperature |
0~40℃ |
| Operation Humidity |
0~95% (w/o condensation) |
| Tested to standards |
LVD: EN62040-1: 2008, |
| EMC requirements: EN62040-2: 2006 |
| Mark |
CE |
| Noise (at 1 meter) |
<52dBA |
<55dBA |
<60dBA |
| Input |
| Voltage |
400V ±20% 3 Phase + N |
| Frequency |
45 ~ 65Hz |
| Power Factor |
≧ 0.99 |
| THDi |
<3% |
| Bypass |
| Voltage |
380/400/415V±10% 3 Phase + N |
| Frequency |
50/60Hz ±3Hz |
| Output |
| Voltage |
380/400/415V 3 Phase + N |
| Voltage Tolerance |
±1% (Static Load) |
| Power Factor |
1 |
| Frequency |
50/60Hz |
| Frequency Tolerance |
50/60Hz ±0.05% (free running) |
| Crest Factor |
03:01 |
| Voltage Harmonic Distortion |
<2% with linear load; |
| <5% with distorting load |
| Overload |
110% for 60 minutes, 125% for 10 minutes, 150% for 1minutes |
| Battery |
| Number of batteries |
32~40pcs configurable |
| Common Battery for Parallel Configuration |
Yes |
| Efficiency |
| VFI Mode |
>93% |
>94% |
>95% |
| ECO Mode |
>97% |
| Backup Mode |
>93% |
>94% |
>95% |
| General |
| Parallel |
Up to 4 units |
| Dimensions (W x D x H) mm |
440 x 780 x 800 |
440 x 780 x 1000 |
600x800x1200 |
| Protection Grade |
IP20 |
| Display and MMI |
4.3" Colorful LCD Touch Screen |
| Built-in Communication Port |
RS-232 (USB), EPO |
| Optional Communication |
2 Communication Slots for |
| SNMP Card, RS-485 Modbus Card, Dry Contact Card |
