| MODEL |
VT625 |
VTPro1000 |
VTPro1500 |
| Input |
Voltage Window |
84-147Vac |
| Frequency |
50/60Hz ±5Hz Auto Sensing |
| Output |
Voltage |
AC Mode |
1st boost 15%(Input-10~-20%);2nd boost: 30%(input -20~-30%);Buck: 15%(Input +10~22.5%) |
| Inv. Mode |
115 ± 10% |
| Frequency |
50/60Hz ± 1Hz |
| Capacity (VA/W) |
625/375 |
1000/600 |
1500/900 |
| Wave Form |
Simulated Sine Wave |
| Transfer Time |
4ms typical |
| Backup Time |
5~30 min. for typical PC Load |
| DC START |
YES |
| Battery |
Type |
Sealed Lead Acid Maintenance Free |
| Capacity |
12V / 7AH |
12V / 7AH |
12V9AH |
| Quantity |
1pcs |
2pcs |
| Voltage |
12Vdc |
24Vdc |
| Recharge Time |
8 hours to 90% |
| Display |
LED |
2 LEDs for Line/Backup and Battery Low/Fault |
4LEDs for Line, Backup, Fault and Overload |
| Self Diagnostics |
Upon Power on and Software Control |
| Alarm |
Audible and Visual |
Line Failure, Battery Low, Overload and Fault Conditions |
| Protection |
Overload |
AC Mode |
> 105% Buzzer continuously alarms |
| Inv. Mode |
> 105% ~ <109% Buzzer continuously alarms
>110% UPS shuts down immediately then alarms 5 seconds |
| Short Circult |
AC Mode |
Input Fuse & Electronic Circuit |
| Inv. Mode |
Electronic Circuit |
| Physical |
Dimensions WxHxD(inch) |
3.7 x 13,9 x 6,7 |
5.8 x 14.2 x 6.2 |
| Outlets(nema 5-15R) Surge/Backup |
2/2 |
0/6 |
| Net Weight (kgs/lbs) |
16.5 |
28.6 |
32.5 |
| Environment |
Operating Temperature |
32 to 104℉ |
| Temperature Warming |
The battery design life is based on a temperature of 77℉ ,
Ambient temperature above this range will affect battery life |
| Humidity |
95% RH Maximum, Non-Condensing |
| COMPUTER INTERFACE |
Interface Type |
USB |
USB (RS232 optional) |
| Compatible Platforms |
Windows 95/98/NT/2000/XP/Vista. Novell Netware , Linux, etc. |
| SAFETY CONFORMANCE |
Quality Type |
ISO9001 Certified |
| Safety Standard |
EN62040-1-1 |
| EMC Standard |
EN62040-2,EN61000-3-2,EN61000-3-3,FCC Class A |
| Marks |
UL,cUL |
| **Specifications subject to change without notice. |
