| CAPACITY |
250W |
360W |
500W |
600W |
900W |
1200W |
| Input |
Voltage Range** |
160Vac~290Vac |
| Frequency Range |
45~65Hz(Auto sensing) |
| Output |
Output Voltage (Battery mode) |
220/230/240Vac ±10% |
| Frequency Range (Battery mode) |
50/60Hz ±1Hz |
| Transfer Time |
2~6ms(typical) |
| Output Waveform |
Simulated SineWave |
| Battery |
Type & Number |
12V/5Ah x 1 |
12V/7Ah x 1 |
12V/9Ah x 1 |
12V/7Ah x 2 |
12V/7Ah x 2 |
12V/9Ah x 2 |
| Recharge Time (to 90%) |
4~6 hours |
| Display |
LCD (Option) |
AC mode, AVR mode, Battery mode, Battery level, Load level, Input voltage, Output voltage, Fault, and Battery weak |
| LED (Standard) |
3 LEDs: Line mode, Battery mode and Fault |
6 LEDs: Line/Battery mode, Fault, Load/Battery level |
| Alarm |
Audible or Visual |
Battery mode / Battery low / Overload / System Fault |
| Protection |
Full Protection |
Overload, Short circuit, Discharge, overcharge and optional RJ-11/RJ-45 surge protection |
| Function |
DC Start |
Yes |
| Plug-in Charging |
Yes |
| Physical |
Dimension (WxHxD, mm) |
100 x 140 x 292 |
148 x 198 x 315 |
| Net Weight (kgs/lbs) |
3.6/7.9 |
4.5/9.9 |
5/11 |
8/17.5 |
11.5/25.3 |
12/26.4 |
| Enviornment |
Operation Temperature |
0- 40°C |
| Operation Humidity |
0-95 % (Without condensing) |
| Altitude |
1000m/3300ft without Derating |
| Noise Level |
≦ 40dB |
| Interface |
Interface (Option) |
USB, RS-232 |
| Compatible Platforms |
Microsoft Windows series, Linux, Mac, etc. |
| Standards and Certifications** |
Safety |
EN62040-1 |
| EMC |
EN62040-2, EN61000-3-2, EN61000-3-3 |
| Marks |
CE |
| |
| * Specifications subject to change without notice, and the final explanation rights are reserved by Ablerex |
| ** Depending on the model and rating voltage, more information please contact with Ablerex |
